Feature | Capability | Description |
|---|
PCB Type | Rigid, Flex, HDI, Power PCB | Support a wide range of PCB layout types, including Rigid, Flex, FPC, HDI, Power PCB, high-speed, and RF designs. |
PCB Layer | Up to 50 Layers | Layout design capability up to 50 layers. PCB manufacturing through JLCPCB currently supports up to 32 layers. |
PAD / PIN Count | 100,000 + PIN | Capable of handling highly complex PCB layouts with 100,000+ pins. |
BGA Pin Spacing | 0.3mm (minimum) | Supports BGA with 0.3mm minimum pitch placement and fanout. |
Trace Width / Spacing | 2.4mil (minimum) | Supports fine routing with minimum trace width/spacing of 2.4mil (0.06mm). |
High Frequency | Up to 60GHz | Professional impedance calculation, controlled impedance routing, and differential pair length matching. |
DFM Check | Full DFM analysis | Manufacturability review with DFM checks, production risk analysis and layout optimisation suggestions. |
Stack-up Design | Multilayer stack-up design | Professional multilayer stack-up design, dielectric planning, copper weight configuration, and impedance matching. |
Lead Time | Delivery within 3 working days (Fastest) | Fast turnaround available — standard PCB layout projects can be delivered in as fast as 3 working days, depending on project complexity and communication efficiency. |
One-Stop Service | Layout + Production Integration | One-stop service: PCB layout is fully optimised for our production process. Orders placed with us after layout completion enjoy smoother ordering, faster production, and higher yield. |
Design for Cost Efficiency | Professional cost optimization | As a PCB manufacturer, we possess professional expertise in reducing production costs. Cost control is considered during the design phase while ensuring that the PCB meets the highest performance and manufacturing standards. |
Order Process | Review first, pay later | Review-first & pay-later mode. We perform initial checks based on uploaded files and requirements before payment and design start, ensuring smooth and efficient order flow. |
Design Visualization | Stage-by-stage visibility & confirmation | The entire design process is split into 3 visible stages: component placement, routing, and final design delivery. Progress is tracked in the system; each step requires customer confirmation before proceeding, reducing rework and ensuring smooth project completion. |
After-Sale Service | Long-term technical support | Long-term after-sales support. Free adjustments are available for production issues or minor schematic changes after delivery (fees may apply for customer-initiated design changes, case by case). |
Design Software | Support for multiple EDA tools | Support for multiple mainstream EDA tools. Our experienced engineering team can handle files from EasyEDA Pro, EasyEDA Standard, KiCad, Altium Designer, and more. |
FAQs about PCB Layout Capabilities
What does JLCPCB PCB Layout service include?
JLCPCB Layout service covers component placement and routing, completed according to the schematic files provided by the customer. Deliverables include Gerber files, BOM, CPL, DXF structural drawings, 3D model files, assembly drawings, and PCB production instructions.
What files are required for a PCB layout service quote?
How long does a PCB layout project usually take, and what affects lead time?
Which PCB design software does JLCPCB support?
Does the layout fee include PCB fabrication? Will production start automatically after the layout is complete?
